Presenting the JMW Screw Extruder Series, an expert and top notch answer for your PET, PA6, PA66, PP, and other comparative materials' dissolving and turning needs.
The JWM series screw extruders are planned with the most recent LTM low-temperature blending parts, guaranteeing astounding plasticizing execution. Our high level assembling strategies ensure high accuracy and remarkable linearity in the development of the screw and barrel.
To additional improve execution, we have consolidated a high-accuracy helical stuff minimizer with solidified gear teeth. This guarantees smooth activity as well as limits commotion levels.
To endure significant hub powers, our screw extruders are outfitted with major areas of strength for super heading. Moreover, we offer the choice to choose imported course and seals, guaranteeing solidness and simple support as per your particular prerequisites.
Pick the JMW Screw Extruder Series for dependable and effective dissolving and turning of your cut or jug cut materials. Experience the distinction of expert grade innovation and accuracy designing.
The JWM series screw extruders are designed to meet the requirements of PP and other comparative materials' dissolving and turning needs. With the latest LTM low-temperature blending components, these extruders ensure excellent plasticizing performance. The advanced manufacturing techniques employed in their production guarantee high precision and exceptional linearity in the construction of the screw and barrel.
To further enhance performance, a high-precision helical gear reducer with hardened gear teeth has been integrated into the design. This not only ensures smooth operation but also minimizes noise levels. In order to withstand significant axial forces, our screw extruders are equipped with robust sections for superior support. Additionally, we offer the option to choose imported bearings and seals, ensuring durability and easy maintenance according to your specific requirements.
Choose the JMW Screw Extruder Series for reliable and efficient dissolving and turning of your cut or bottle-cut materials. Experience the difference of professional-grade technology and precision engineering.
Date Sheet
JWM Extruder spec | Screw dia mm | L/D | Max output for PET kg/h | Max output for PA6 kg/h | Screw Rotational Speed r/min | Transmission power KW | Heating power KW | Heating Section | Heating voltage V | Center heighe mm | Weight ton |
| JWM20/25 | Ꝋ20 | 25:1 | 6 | 4 | 20-90 | 2.2 | 3 | 3 | 220 | 340 | 0.6 |
| JWM25/25 | Ꝋ25 | 25:1 | 8 | 5.5 | 20-90 | 2.2 | 3 | 3 | 220 | 340 | 0.7 |
| JWM30/25 | Ꝋ30 | 25:1 | 12 | 8 | 20-90 | 3 | 3 | 3 | 220 | 340 | 0.8 |
| JWM40/25 | Ꝋ40 | 25:1 | 28 | 19 | 20-90 | 5.5 | 6 | 3 | 220 | 340 | 0.9 |
| JWM45/25 | Ꝋ45 | 25:1 | 35 | 24 | 20-90 | 7.5 | 8 | 3 | 220 | 340 | 1 |
| JWM50/25 | Ꝋ50 | 25:1 | 55 | 38 | 20-90 | 7.5 | 14 | 4 | 220 | 340 | 1.1 |
| JWM55/25 | Ꝋ55 | 25:1 | 65 | 45 | 20-90 | 11 | 15 | 4 | 220 | 340 | 1.2 |
| JWM65/25 | Ꝋ65 | 25:1 | 85 | 60 | 20-90 | 18.5 | 16 | 5 | 220 | 340 | 1.3 |
| JWM75/25 | Ꝋ75 | 25:1 | 100 | 70 | 20-80 | 22 | 21 | 5 | 220 | 410 | 1.6 |
| JWM80/25 | Ꝋ80 | 25:1 | 125 | 85 | 20-80 | 37 | 27 | 5 | 220 | 510 | 1.8 |
| JWM90/25 | Ꝋ90 | 25:1 | 180 | 125 | 20-80 | 45 | 32 | 5 | 220 | 510 | 2 |
| JWM105/25 | Ꝋ105 | 25:1 | 280 | 195 | 20-70 | 55 | 45 | 5 | 220 | 610 | 3 |
| JWM120/25 | Ꝋ120 | 25:1 | 380 | 260 | 20-60 | 75 | 54 | 6 | 220 | 660 | 3.5 |
| JWM130/25 | Ꝋ130 | 25:1 | 450 | 310 | 20-60 | 90 | 57 | 6 | 220 | 660 | 4 |
| JWM135/25 | Ꝋ135 | 25:1 | 500 | 350 | 20-60 | 90 | 63 | 6 | 220 | 660 | 4.2 |
| JWM150/25 | Ꝋ150 | 25:1 | 600 | 415 | 20-60 | 110 | 76.5 | 6 | 380 | 710 | 5 |
| JWM160/25 | Ꝋ160 | 25:1 | 700 | -- | 20-60 | 132 | 85.5 | 6 | 380 | 710 | 6 |
| JWM170/25 | Ꝋ170 | 25:1 | 800 | -- | 20-60 | 160 | 103.5 | 6 | 380 | 750 | 8 |
| JWM180/25 | Ꝋ180 | 25:1 | 900 | -- | 20-50 | 185 | 110 | 7 | 380 | 800 | 10 |
| JWM200/25 | Ꝋ200 | 25:1 | 1050 | -- | 20-50 | 220 | 150 | 7 | 380 | 1000 | 12 |
Sustainability saves money
Automation makes processes more efficient
Digital plants help you maintaining the overview
Easy maintenance ,faster start up
Enterprise Honors
Company profile
JWELL Fiber Machinery Co.，Ltd (SUZHOU), its predecessor was Shanghai JWELL Chemical Fiber Company, with nearly 30 years of accumulation, has grown into a national high-tech enterprise and a globally well-known manufacturer of chemical fiber spinning equipment since its establishment in1997. The company locate in the Yangtze River Delta core zone—Chengxiang Industrial Park, Taicang City, Jiangsu Province, owned 20-hectare smart manufacturing base featuring 12,000㎡ of modern workshops equipped with precision CNC machining centers and intelligent assembly lines, enabling an annual production capacity of 1,000+ units. JWELL is committed to providing global customers with end-to-end intelligent equipment solutions, from R&D to mass production.
